Excelon Performance & Quality
eXcelon products incorporate the latest technologies and deliver the highest sonic performance.  From advanced audio tuning capabilities, crossover and equalizer systems, high voltage preouts and two-year warranty, eXcelon represents the very best product available.

Assymetrical 4-Ch. Design
A unique staggered power supply design allows the amplifier to run in 4-channel mode for demanding front and rear speakers or 3-channel mode for front speakers plus enough power to drive a subwoofer at 300W RMS bridged simultaneously.






Variable High-Pass Filter
Filters low frequencies out of the music and passes only signals above a certain frequency (called the cut-off frequency) to mid and high range speakers.

Variable Low-Pass Filter
Filters high frequencies out of the music and improves efficiency and sound quality by allowing only the low frequencies to pass to the subwoofer.

Variable Bass Boost
Adjust the fixed bass boost frequency (40Hz) to maximize natural bass performance.

General Features:

  • Pulse Width Modulated MOSFET power supply
  • LED power (green) and protect (red) indicators
  • Variable Bass Boost (0 to +18 dB, 5th channel only)
  • Soft start turn-on
  • 4/3/2 channel operation
  • 3-way protection circuitry (thermal, overload, and speaker short protection)
  • Heavy duty aluminum alloy heat-sink for extreme heat dissipation
  • Nickel-plated RCA level inputs
  • Nickel-plated screw terminals
  • Input sensitivity:
    • Low level: 125mV-5V
    • High level: 250mV-10V
  • Variable high-pass filter (50-200 Hz, 24 dB/octave)
  • Variable low-pass filter (50-200 Hz, 24 dB/octave)
  • CEA-2006 compliant amplifier
  • Frequency response: 5-50000 Hz
